Agrandir l’espace disque d’une machine virtuelle en LVM

Le but est d’agrandir le disque dur virtuel de la machine virtuelle. Il faut que le disque de la machine virtuelle soit configurée en LVM.

  • DomO = Serveur de virtualisation Xen qui héberge les VM
  • DomU = VM
  • LV = volume logique
  • VG = Groupe de volume

Sur le DomO :

  • Agrandissement d’un LV d’une VM de 250G:
  • Arreter la VM

Identifier le disque de la VM en question puis :

lvextend -L +250G /dev/vg/lv_ispconfig
  • Redémarrer la VM

Nous allons modifier la table des partitions pour prendre en compte l’espace disque rajouté : Sur la VM

# fdsik /dev/xvda  Command (m for help): p  Disk /dev/xvda: 53.7 GB, 53687091200 bytes 255 heads, 63 sectors/track, 6527 cylinders, total 104857600 sectors Units = sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x0006d2da     Device Boot      Start         End      Blocks   Id  System /dev/xvda1            2048      499711      248832   83  Linux /dev/xvda2          501758   104855551    52176897    5  Extended /dev/xvda5          501760   104855551    52176896   8e  Linux LVM
  • IMPORTANT : Les valeurs importante sont la partition /dev/xvda5 qui commence à 501760
  • Nous allons supprimer le volume étendue /dev/xvda2 puis le re créer pour prendre en compte le nouvelle escape libre :
fdisk /dev/xvda  Command (m for help): p
Disk /dev/xvda: 322.1 GB, 322122547200 bytes 255 heads, 63 sectors/track, 39162 cylinders, total 629145600 sectors Units = sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x0006d2da      Device Boot      Start         End      Blocks   Id  System /dev/xvda1            2048      499711      248832   83  Linux /dev/xvda2          499712   629145599   314322944    5  Extended /dev/xvda5          501760   629145599   314321920   8e  Linux LVM  Command (m for help): d

Partition number (1-5): 2
Command (m for help): n
Partition type:    p
primary (1 primary, 0 extended, 3 free)    e
extended Select (default p): e
Partition number (1-4, default 2):  Using default value 2

First sector (499712-629145599, default 499712):  Using default value 499712 Last sector, +sectors or +size{K,M,G} (499712-629145599, default 629145599):  Using default value 629145599

Command (m for help): n
Partition type:    p
primary (1 primary, 1 extended, 2 free)    l
logical (numbered from 5) Select (default p): l
Adding logical partition 5 First sector (501760-629145599, default 501760):  Using default value 501760 Last sector, +sectors or +size{K,M,G} (501760-629145599, default 629145599):  Using default value 629145599
Command (m for help): t
Partition number (1-5): 5 Hex code (type L to list codes): 8e
Changed system type of partition 5 to 8e (Linux LVM)

Command (m for help):w

# fdisk /dev/xvda  Command (m for help): p
Disk /dev/xvda: 322.1 GB, 322122547200 bytes 255 heads, 63 sectors/track, 39162 cylinders, total 629145600 sectors Units = sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disk identifier: 0x0006d2da      Device Boot      Start         End      Blocks   Id  System /dev/xvda1            2048      499711      248832   83  Linux /dev/xvda2          499712   629145599   314322944    5  Extended /dev/xvda5          501760   629145599   314321920   8e  Linux LVM

Le nouvelle espace est pris en compte dans la table de partion

  • Maintenant il faut augmenter la VG puis la LV en question :Avant
# pvs PV         VG   Fmt  Attr PSize   PFree  /dev/xvda5 isp1 lvm2 a--  50g     0  # ls /dev/isp1/ home  root  swap_1  tmp  usr  var  # lvs  LV     VG   Attr     LSize   Pool Origin Data%  Move Log Copy%  Convert  home   isp1 -wi-ao--  10,00g                                            root   isp1 -wi-ao--   3,44g                                            swap_1 isp1 -wi-ao--   4,78g                                            tmp    isp1 -wi-ao-- 380,00m                                            usr    isp1 -wi-ao--   8,38g                                            var    isp1 -wi-ao-- 20,79g
  • On augmente le VG pour prendre en compte l’espace libre ajouté :
# pvresize /dev/xvda5 Physical volume "/dev/vda2" changed   1 physical volume(s) resized / 0 physical volume(s) not resized# pvs PV         VG   Fmt  Attr PSize   PFree  /dev/xvda5 isp1 lvm2 a--  299,76g 50,00g
  • On veut augmenter la partition LV var

NEW

lvextend -r -L +150G /dev/vg_isp/lv_var

-> Plus besoin  de démonter, killer et rebooter

OLD

  • On démonte la partition :
umount /dev/isp1/var
e2fsck /dev/isp1/var
resize2fs /dev/isp1/var #(peut etre long suivant la taille ajouté)

Et voilà !

lvs  LV     VG   Attr     LSize   Pool Origin Data%  Move Log Copy%  Convert  home   isp1 -wi-ao--  10,00g                                    root   isp1 -wi-ao--   3,44g                                            swap_1 isp1 -wi-ao--   4,78g                                            tmp    isp1 -wi-ao-- 380,00m                                            usr    isp1 -wi-ao--   8,38g                                            var    isp1 -wi-ao-- 222,79g
  • On remonte les partitions à leur point de montage :
mount -a
  • On pourra redémarrer la VM pour être sure que ton est OK
